ALL SERIES
DDPro269
DDP269S
DDP269M
DDP269L
DDP269L
PMMA & PC lens with excellent transparency and optical performace,anti-aging,uvioresistant;
IP66 protection level and IK09 with tempered glass;
Adjustable bracket and superior stainless steel nuts;
Die casting aluminum (ADC12) lamp housing structure provides perfect heat dissipation;
High quality LED chip ensures good reliability and consistency;
Fixture color can be customized.
| Model No. | DDP269S | DDP269M | DDP269L | DDP269L |
|---|---|---|---|---|
| Typical Power | 100w | 200w | 300w | 400w |
| Typical Efficacy(Lm/W) |
140(SMD3030) 160(SMD5050) |
140(SMD3030) 160(SMD5050) |
140(SMD3030) 160(SMD5050) |
140(SMD3030) 160(SMD5050) |
| Luminous Flux(Lm) |
14000(SMD3030) 16000(SMD5050) |
28000(SMD3030) 32000(SMD5050) |
42000(SMD3030) 48000(SMD5050) |
56000(SMD3030) 64000(SMD5050) |
| Input Voltage | AC 100-277V 50/60Hz | |||
| LED Driver | INVENTRONICS / MOSO / PHILIPS / SOSEN (available on request) | |||
| Power Factor | ≥0.95 | |||
| Power Efficiency | ≥90% | |||
| LED Components | SMD 3030 & SMD 5050 | |||
| CCT | 3000K / 4000K / 5000K / 5700K | |||
| CRI | Ra≥70 (80,90 customized according to project requirements) | |||
| Beam Angle | 30° / 60° / 90° / 120° / 113x97° / P50° / T II-M / T III-M / T IV-M / T V-M | |||
| IP | IP66 | |||
| IK | IK09 | |||
| Working Environment | -20℃~+45℃ | |||
| RH | 20%~90% RH | |||
| LED Lifespan | 100,000 Hours | |||
